Hi-Amp Circuit Protector (Breaker) Auto Reset
Typically used in auxiliary and accessory circuits in truck, bus', RVs and marine applications. Others include battery charger and DC audio system.
Voltage:32Vdc
Rated Current:100A
Termination?1/4" Stainless Steel Studs
Mounting:Surface Mount
Reset: TypeT1, Auto Reset
Operating Temperature:-32oC (-25oF) to 82oC (180oF)
Storage Temperature:-34oC (-30oF) to 149oC (300oF)
Interrupt Capacity:3,000A @ 32Vdc
Dust and Waterproof: IP67
BodyUL-rated 94V0 thermoset plastic
Length: 2.913inch
Width: 1.900inch
Height: 1.091inch
Weight:88 g
Regulatory SpecificationInterrupt Capacity: SAE J1625; SAE J553, ABYC-E11; UL 1077*
Ignition Protected: SAE J1171; UL 1500*
Endurance: SAE J1625; SAE J553
Shock, Vibration, Corrosion, Humidity: Mil-STD-202
Type 1 Auto Reset 100a
1/4"-28 threaded studs, Extended Surface Mount
High Amp Thermal Circuit Breakers,100 AMP,Max 32Vdc
UL-rated 94V0 thermoset plastic,IP67 Waterproof Rated & Ignition Protected
Typically used in auxiliary and accessory circuits in truck, bus', RVs ,Solar and marine applications. Others include battery charger and DC audio system
